Bundle Clips

For use with thimble eye wire rope choker slings
Used in pre-slinging tubular loads
Forged saddle marked with FORGED USA, Size, Date Code and Campbell logo
Saddles, U-bolt with heavy hex nuts are galvanized to ASTM A-153
U-bolt is colored blue for easy identification
Meets requirements of ASME 30.26
NOTE: Bundle clips nuts should be tightened with a torque wrench: tightening can be accomplished progressively by applying torque alternately to each nut in increments of ten percent of the torque value

For Rope Diameter	Catalog No.	UPC No. 020481	Torque Valve	Clips Per Box	A Dim.	B Dim.	C Dim.	D Dim.	E Dim.	F Dim.	Weight Each
3/4 in	T6991294	257780	130 ft/lb	20	1-1/2 in	2-13/16 in	3-5/16 in	5/8 in	1-1/16 in	2-5/16 in	2.20 lb
