Grade 80 – Cam-Alloy Chain Slings

Cam-Alloy steel chain is electrically welded alloy steel embodying the latest manufacturing technology. Alloy provides a superior chain sling with high tensile strength and excellent wear resistance. The following chains meet or exceed all existing OSHA, ANSI, ASME, NACM, and ASTM specification requirements.

The Cam-Alloy chain and attachments used in fabricating Campbell chain slings offer a design factor of 4 to 1. System 8 is Campbell’s trade name for grade 80 chain. System 10 is Campbell’s trade name for grade 100 chain.

Product Description

Trade Size		Grade	Material Diameter		Inside Dimensions				Drum		Working Load Limit		Feet/Drum	Lb/100ft.	Links/ft.
Trade Size			Material Diameter		Length		Width		Drum		Working Load Limit
in.	mm		in.	mm	in.	mm	in.	mm	Cat. No.	UPC No. 020418	lb	kg
9/32	7	100	.29	7	.86	22	.41	10	0405212	182204	4300	1950	500	74	13.8
5/16	8	80	.32	8	.94	24	.46	12	0400512	063367	4500	2000	500	92	12.8
5/16	8	100	.33	8	1.01	26	.50	13	0405312	245510	5700	2600	500	104	12
3/8	10	100	.40	10	1.22	31	.57	14	0405412	182211	8800	3990	500	148	10.0
1/2	13	100	.52	13	1.57	40	.75	19	0405512	182228	15,000	6800	300	250	7.8
5/8	16	100	.64	16	1.93	49	.87	22	0405612	0405612	22,600	10,250	200	379	6.5
3/4	20	100	.80	20	2.42	61	1.09	28	0405712	182242	35,300	16,000	100	610	4.9
7/8	22	100	.88	22	2.70	69	1.28	31	0405812	063497	42,700	19,400	100	775	4.4
1	26	80	1.00	25	2.80	71	1.40	36	0401612	063510	47,700	21,600	100	965	4.3
1 1/4	32	80	1.25	32	3.50	89	1.75	44	0402012	063534	72,300	32,800	60	1525	3.5

The last digit of the catalog number changes to a 1 if a non-standard quantity is ordered.

NOTICE: The product specifications and dimensions are as accurate as possible at the time of printing. However, because we are constantly improving the quality and design of our product, they can change without notice.

Purchasers please note that all “Warnings and Cautions” apply to chain, components, and fittings as well as chain slings. Purchasers are responsible for conveying the “Warnings and Cautions” including the “Inspection, Care and Proper Use” section information to the end user. Campbell denies any liability for damage that results from use in excess of the working load limit or any abuse or misuse of the product. Any questions concerning the use of Campbell products may be directed to your Apex Tool Group Sales Representative or Customer Service.
