GR 100 Alloy Chain

Specifically recommended for overhead lifting applications
25% stronger than grade 80 which enables you to perform same lifts with lighter weight chain
Standard material: alloy steel, heat-treated
Standard finish: bright
Hallmarking: “C10”, “USA”, and traceability code
Proof-tested
Design factor: 4 to 1
Packaged in drums, order unit is “feet”
Made in the USA
DO NOT EXCEED THE WORKING LOAD LIMIT

Trade Size	Catalog No.	UPC No. 020418	Material Dia.	Inside Length	Inside Width	WLL	Feet Per Package	Links Per Foot	Weight Per Package
9/32	0405212	182204	0.29 in	0.87 in	0.41 in	4300 lb	500 ft	13.8	370 lb
5/16	0405312	245510	0.33 in	1.01 in	0.50 in	5700 lb	500 ft	12	520 lb
3/8	0405412	182211	0.40 in	1.22 in	0.57 in	8800 lb	500 ft	10	740 lb
1/2	0405512	182228	0.52 in	1.58 in	0.75 in	15000 lb	300 ft	7.8	750 lb
5/8	0405612	182235	0.64 in	1.93 in	0.87 in	22600 lb	200 ft	6.5	758 lb
3/4	0405712	182242	0.80 in	2.42 in	1.09 in	35300 lb	100 ft	5.5	598 lb
7/8	0405812	152924	0.88 in	2.70 in	1.28 in	42700 lb	100 ft	4.4	775 lb
